Dlink DGS-F1010P-E 250M 10-Port 1000Mbps Switch with 8 PoE Ports and 2 Uplink Ports
DGS-F1010P-E features eight 10/100/1000 BASE-T ports that support the IEEE 802.3af and IEEE 802.3at PoE protocols, supplying up to 30 W on each PoE port up to 250m and providing a total power budget of 96 W. You can connect compatible devices to the DGS-F1010P-E without using an additional power supply. This allows you to save on cabling and to install devices in locations without immediate access to power outlets.
High PerformanceThe DGS-F1010P-E features plug-and-play installation and requires no configurations. Auto MDI/MDI-X support on all ports removes the need for crossover cables when connecting to another switch or hub, and auto-negotiation on each port intelligently adjusts the port speed for compatibility with the connected device. With wire-speed filtering and store-and-forward switching, the DGS-F1010-E maximizes network performance while minimizing the transmission of bad network packets.
The D-Link DGS-F1010P-E 10 Port 10/100/1000 Switch with 8 PoE Ports enables you to connect Power over Ethernet (PoE) devices such as wireless access points (APs), IP cameras, and IP phones to the network. Built with home and small business users in mind, the DGS-F1010P-E is compact and operates silently making it ideal for most rooms and offices Power over Ethernet
Built for your Need
Robust and cost-effective PoE solution to provide power for your PoE powered devices such as IP cameras, CCTV, VoIP, AP etc.
Up to 250m PoE and Data Transmission
Equipped with PoE extend technology, DGS-F1010P-E have the capability to supply 802.3af/at PoE up to 250m with data transmission. Cost saving for long distance solution.
6KV Surge Protection
D-Link 250M is enhanced with 6KV surge protection Effectively guard equipment from lighting damage especially if use on AP/IP camera install outdoor or at higher position.
Enhanced with VLAN Function
With a flick of button, Isolate the downlink port to each other can effectively suppress network storms and improve network performance.
Enhanced with Video QoS
Improve the Video Packet Priority Create high priority for video streaming, perfect solution for IP camera/CCTV.
Intelligent Detection
Automatically Detect unresponsive PoE device and reboot the device for recovery.
Technical Specifications
| Brand | D-Link |
| Model Name | PoE Switch |
| Model No. | DGS-F1010P-E |
| RJ45 Ports | port 9~port 10 |
| Dimensions | 84 x 94 x 27mm |
| Weight | 1.05kg |
| Performance | Bandwidth: 20 Gbps (no block), Network delay (100 to 100M bps): maximum 20 ?s (using 64byte packet), Frame filtering and transmission rate, 10M: 14,800pps, 100M: 148,800pps, 1000M: 1488,00pps |
| Warranty | 1 Year |
