Mercury Elite 2000 Pro 2KVA Offline UPS
Mercury Elite 2000 Pro Line Interactive UPS provides a relatively robust capacity for power backup to meet office as well as domestic power backup demands. With the Mercury Elite 2000 you not only get power backup for your equipment but also enjoy solid protection for those appliances. The built-in AVR function of the Elite 2000 Pro means dangerous power fluctuations won’t easily make mincemeat of your equipment.
The Mercury UPS is designed with advanced technology to deliver efficient performance and durability. Here’s part of the benefits you enjoy in using a Mercury Elite Pro UPS:
Designed with Wide input voltage range to meet local voltage challenges
Rugged enough to withstand generators
Offers Overload protection
There’s also Short circuit protection
Built-in AVR to cope with power fluctuations
Battery deep discharge protection & overcharge protection
Simply put, you get a tough, tropicalized UPS that will meet the challenges of each day.
Technical Specifications
Check the details below:
| Rating input voltage | 2000 VA / 1200 W |
| Rating input frequency | 60/50Hz (auto sensing) |
| Input phase | Single phase |
| Input socket | With Fuse |
| Cold Start (0 to 100% load) | Press the ON/OFF Switch |
| Input Range (220V) | 140-300 |
| Rating output(VA) | 2000 |
| Rating output (W) | 1200 |
| Power factor | 0.6 |
| Rating output voltage (V) | 220 |
| Waveform | Battery mode (simulated sine wave), AC mode(sine wave) |
| AC Voltage Regulation | ±10% (Battery mode) |
| Rear output socket | 4 x Universal – Battery backup |
| Waveform | Simulated Sine Wave (Battery mode) |
| Line Mode | Synchronize with the utility |
| Rating frequency | 60Hz or 50 Hz ± 1 Hz |
| Battery Mode | Yellow flashing |
| Short circuit protection Line Mode | Fuse & Firmware protection |
| Short circuit protection Battery Mode | Firmware Protection |
| Overload protection Line Mode | 110%±5%; Go to fault mode Line Mode after 5 minutes, 120%±5%; Go to fault mode immediately. |
| Overload protection Battery Mode | 110%±5%; Shutdown after 5 seconds, 120%±5%, Shutdown immediately |
| Indicators AC mode | Green Lighting |
| Indicators Battery Mode | Yellow Flashing |
| Indicators Fault | Red Lighting |
| Alarm Battery Mode | Sounding every 10 Seconds |
| Alarm Low Battery | Sounding every Second |
| Alarm Overload | Sounding every 0.5 second |
| Alarm Fault | Continuously sounding |
| Full Protection | Overload, discharge, and Overcharge protection |
| Transfer Time | Typical 2-6ms, 10ms max. |
| Transfer Time | Typical 2-6ms, 10ms max. |
| Communication Interface | Optional RS232/RJ11 |
| Battery and runtime Rating | 2 X 12V/9AH |
| Recharge time – Typical | 6-8 hours recover to 90% capacity |
| Charge current | About 1A at normal mode. |
| Dimension, D X W X H (mm) | 390 x 125 x 225 |
